Enhance Your Crushing Efficiency with Premium VSI Crusher Parts
In the demanding world of aggregate and mining industries, achieving optimal performance from your VSI (Vertical Shaft Impact) crusher is essential for maximizing productivity and reducing downtime. The quality and reliability of VSI crusher parts play a crucial role in ensuring your equipment runs efficiently. At Europe Parts, we specialize in providing high-performance VSI crusher parts that deliver superior durability, precision, and wear resistance. From feed tubes to rotor tips, we have everything you need to keep your VSI crusher running at peak performance. In this article, we will explore the benefits of our VSI crusher parts and why they are the best choice for your crushing needs.
Why Choose Our VSI Crusher Parts?
1. Premium Quality Materials for Maximum Durability
Our VSI crusher parts are made from high-quality materials such as tungsten carbide and hardened steel to withstand the harshest crushing environments. These materials provide excellent wear resistance and durability, ensuring that the parts can handle the high-impact stresses associated with VSI crushers. Whether you are processing granite, limestone, or other hard materials, our VSI crusher parts are designed to last longer and reduce the need for frequent replacements.
2. Optimized Design for Superior Performance
Each VSI crusher part is meticulously engineered to enhance the performance of your crusher. The feed tube and feed eye ring, for example, are designed to ensure a smooth and consistent flow of material into the crusher, reducing wear and increasing throughput. Similarly, our top and bottom wear plates, trail plates, distributor plates, and rotor tips are optimized to improve the crusher’s efficiency, reduce energy consumption, and minimize operational costs. Also all rotors passes with computerized balance machine for superior service life.
3. Comprehensive Range of Wear Parts
At Europe Parts, we offer a comprehensive range of VSI crusher parts to suit various applications and crusher models. Our product lineup includes:
- Feed Tube and Feed Eye Ring: Designed to ensure consistent material feed and protect the crusher from excessive wear.
- Top and Bottom Wear Plates: Provide maximum protection to the crusher’s frame and reduce wear on key components.
- Trail Plates: Enhance material flow and reduce the risk of clogging, ensuring smooth operation.
- Distributor Plate: Distributes the feed evenly across the rotor, improving crushing efficiency and reducing wear.
- Upper and Lower Wear Plates: Protect the rotor from wear and extend its service life.
- Tip / Cavity Wear Plates (TCWP): Specifically designed to protect the rotor tips and reduce wear in high-impact areas.
- Back-up Tip: Provides additional protection to the rotor tips, extending their service life.
- Rotor Tips: Made from high-quality materials to deliver superior wear resistance and impact protection.
4. Custom-Made Parts for Your Specific Needs
We understand that every crushing operation is unique, which is why we offer custom-made VSI crusher parts to meet your specific requirements. Whether you need a particular size, material, or design, our team of experts can work with you to develop custom solutions that enhance your crusher’s performance and extend its service life. For more information on our custom solutions, visit our custom parts page.
5. Enhanced Efficiency and Reduced Downtime
Using high-quality VSI crusher parts can significantly improve your crusher’s efficiency and reduce downtime. Our precision-engineered parts are designed to fit perfectly with your VSI crusher, ensuring smooth operation and reducing the risk of unexpected failures. This not only boosts productivity but also minimizes maintenance costs, allowing you to achieve better results with less effort.
6. Easy Installation and Maintenance
Our VSI crusher parts are designed for easy installation and maintenance, reducing downtime and labor costs. The modular design of our parts allows for quick and hassle-free replacement, ensuring that your crusher remains operational with minimal interruptions. For detailed installation instructions, check out our installation guide.
7. Cost-Effective Solutions
Investing in high-performance VSI crusher parts from Europe Parts is a cost-effective choice for any crushing operation. Our parts are designed to provide long-lasting performance, reducing the need for frequent replacements and lowering your overall maintenance expenses. By choosing our VSI crusher parts, you are making a smart investment that will pay off in the long run.
8. Environmentally Friendly Options
At Europe Parts, we are committed to sustainability and environmental responsibility. Our VSI crusher parts are designed to minimize waste and reduce environmental impact by extending the life cycle of your equipment. By choosing our products, you contribute to a more sustainable approach to crushing operations. Learn more about sustainability in crushing operations.
Conclusion
Maximizing the efficiency and productivity of your VSI crusher requires high-quality, reliable parts that can withstand the rigors of heavy-duty crushing. At Europe Parts, we offer a comprehensive range of VSI crusher parts designed to deliver superior performance, durability, and value. From feed tubes and wear plates to rotor tips and custom-made solutions, we have everything you need to keep your VSI crusher running at its best. Contact us today to learn more or visit our product page to explore our full range of VSI crusher parts.
External Link:
Learn more about Vertical Shaft Impact crushers on Wikipedia.
Internal Link:
Explore more about our VSI Crusher Parts on Europe Parts.
BARMAC B7150 VSI Crusher and Parts
| Item Name | Item Code | QTY | Weight (kg) |
|---|---|---|---|
| Rotor Assembly No.1 | MM0407475 | 1 | 662 |
| Rotor Taper Lock MkII No.2 | B96394007A | 1 | 14.5 |
| Rotor Taper Lock MkII No.2 | B96394007B | 1 | 11 |
| Feed Tube No.3 | B962S7040B | 1 | 15.3 |
| Distributor No.4 | B96394120E | 1 | 35 |
| Screw No.5 | 7001530521 | 1 | N/A |
| Feed Eye Ring No.6 | B96334030E | 1 | 20 |
| Upper Wear Plate No.7 | B96334135A | 1 | 20.1 |
| Lower Wear Plate No.8 | B96334140A | 1 | 27.3 |
| Rotor Tip Set No.9 | B96394049O | 3 | 5.6 |
| Cavity Wear Plate No.10 | B96394150N | 4 | 7.2 |
| Cavity Wear Plate Bolt Set No.11 | B96394150O/B | 3 | N/A |
| Trail Plate Set – Wide No.12 | B90394055B | 1 | 4.5 |
| Backup Tip Set Short No.13 | B90394060A | 1 | 2 |
| Backup Tip Set Long No.14 | B96394060B | 1 | 4 |
| Cavity Wear Plate No.15 | B96394150O | 2 | 6.3 |
Barmac B9100 VSI Crusher and Parts
| Item Name | Item Code | QTY | Weight (kg) |
|---|---|---|---|
| Rotor Assembly | B9100-Rotor | 1 | N/A |
| Rotor Tip | B9100-Tip | 3 | N/A |
| Cavity Wear Plate | B9100-CavityWP | 4 | N/A |
| Upper Wear Plate | B9100-UpperWP | 1 | N/A |
| Lower Wear Plate | B9100-LowerWP | 1 | N/A |
| Distributor Plate | B9100-DistPlate | 1 | N/A |
| Feed Eye Ring | B9100-FER | 1 | N/A |
| Backup Tip | B9100-BackupTip | 3 | N/A |
| Tip Cavity Wear Plate | B9100-TCWP | 3 | N/A |
| Trail Plate | B9100-TrailPlate | 1 | N/A |
Trio TV95 VSI Crusher and Parts
| Item Name | Item Code | QTY | Weight (kg) |
|---|---|---|---|
| Rotor Assembly | TVS325.00(YL) | 1 | 712 |
| Rotor Frame | TVS325.1 | 1 | 159 |
| Wear Plate | TVS325-5 | 10 | 10 |
| Tungsten Tip (Outer) | TVS325.3(YL) | 5 | 9 |
| Center Distributor | TVS325-802 | 1 | 48 |
| Feed Eye Ring | TVS325-3 | 1 | 37 |
| Vertical Wear Bar (Outer) | TV325-6 | 5 | 9 |
| Bottom Protection Plate | TV325B.4 | 1 | 75 |
| Top Protection Plate | TVR325.2 | 1 | 62 |
| Rotor Tip | TVI356.4 2A(YL) | 5 | 9 |
| Distributor Ring | TVS325-801 | 1 | 27 |
| Vertical Liner | TVS325-9 | 5 | 1 |
| Rotor Boss | TV325-10 | 1 | 90 |
| Bushing | TV325-11 | 1 | 12 |
Sandvik CV215 VSI Crusher Parts List:
| Item Name | Item Code | Typical Quantity |
|---|---|---|
| VSI Turbo Tip Hard Set | 488.1801-901 | 3 |
| Back-Up Tip Set | 488.0368-901 | 3 |
| Trail Plate Set | 488.1118-901 | 2 |
| Turbo Cavity Wear Part Set (Lower) | 488.1565-901 | 1 |
| Turbo Cavity Wear Part Set (Upper) | 488.1662-901 | 1 |
| Upper Wear Plate Set | 488.085-901 | 3 |
| Lower Wear Plate Set | 488.0851-901 | 3 |
| Distributor Locating Pin Set | 488.1513-901 | 1 |
| Top Wear Plate Set | 488.0853-901 | 3 |
| Distributor Plate | 488.077-901 | 1 |
| Feed Tube | 485.0091-901 | 1 |
| Top Plate | 488.0769-901 | 1 |
CANICA 2000 VSI Crusher and its parts:
| Item Name | Item Code | Quantity | Weight (kg) |
|---|---|---|---|
| Rotor Assembly | CJ08700-340-01-2 | 1 | 560 |
| Rotor Weldment | CJ08700-340-02 | 1 | 250 |
| Wear Plate UPR/LO | CJ04431848 | 10 | 9 |
| Rotor Tip | CJ08700-340-17 | 5 | 9 |
| Top Wear Plate | CJ08700-340-27 | 3 | 31 |
| Wall Plate | CJ08700-340-05 | 10 | 6 |
| Distributor Plate | CJ04431850 | 1 | 27 |
| Washer | CJ08700-340-09 | 10 | 0 |
| Liner Upper | CJ08700-340-22U | 5 | 2 |
| Liner Lower | CJ08700-340-22L | 5 | 2 |
| Feed Tube | CJFT0400 | 1 | 87 |
Barmac B6150 VSI Crusher and Parts
| Item Name | Item Code | Quantity | Weight (kg) |
|---|---|---|---|
| Rotor Assembly 690 DTR | MM0407471 | 1 | 305 |
| Taper Lock | B69274007A | 1 | 7.4 |
| Feed Tube | B702S7040A | 1 | 14 |
| Distributor | B69274120C | 1 | 16 |
| Screw | 7001530521 | 1 | N/A |
| Feed Eye Ring | B69274030F | 1 | 7 |
| Upper Wear Plate Set | B69274135A | 1 | 14 |
| Lower Wear Plate Set | B69274140A | 1 | 13.5 |
| Rotor Tip Set | B96394049O | 2 | 5 |
Barmac 990 VSI Crusher and Parts
| Item Name | Item Code | Quantity | Weight (kg) |
|---|---|---|---|
| Basic Rotor Assembly | MM0407477 | 1 | 616 |
| Tapered Sleeve Rotor Taper Lock – Mk III | B96394007B | 1 | 11 |
| Feed Tube | B962S7040B | 1 | 15.3 |
| Distributor | B96394120C | 1 | 33 |
| Distributor | B96394120B | 1 | 26 |
| Distributor | B96394120E | 1 | 35 |
| Distributor | B96394120F | 1 | 35 |
| Screw | 7001530521 | 1 | N/A |
| Feed Eye Ring | B96394030E | 1 | 20 |
| Upper Wear Plate | B96394135A | 1 | 20.1 |
| Lower Wear Plate | B96394140A | 1 | 27.3 |
| Rotor Tip Set | B96394049E | 3 | 5.6 |
| Rotor Tip Set | B96394049G | 3 | 5.6 |
| Rotor Tip Set | B96394049I | 3 | 5.6 |
| Rotor Tip Set | B96394049K | 3 | 5.6 |
| Rotor Tip Set | B96394049M | 3 | 5.6 |
| Rotor Tip Set | B96394049O | 3 | 5.6 |
| Rotor Tip Set | B96394049Q | 3 | 5.6 |
| Cavity Wear Plate | B96394150O | 2 | 6.3 |
| Cavity Wear Plate | B96394150N | 4 | 7.2 |
| Cavity Wear Plate Bolt Set | B96394150O/B | 3 | N/A |
| Trail Plate Set | B90394255B | 1 | 3 |
| Trail Plate | B90394055A | 1 | 3.9 |
| Trail Plate | B90394055B | 1 | 4.5 |
| Backup Tip Set Short | B90394060A | 1 | 2 |
| Backup Tip Set Long | B90394060B | 1 | 4 |
